3300lbs Electric Pallet Truck
Regular price
$1,551.00
Regular price
$2,068.00
-25%
Sale price
$1,551.00
Couldn't load pickup availability
Li-ion Powered Pallet Truck
Indoor using type Li-ion powered pallet truck, with similar size as manual pallet truck,offer small turning radius, it is super lignt and easy to operate.
Li-ion Powered Pallet Truck
Indoor using type Li-ion powered pallet truck, with similar size as manual pallet truck,offer small turning radius, it is super lignt and easy to operate.
| Item | Unit/Code | Value |
|---|---|---|
| Drive | - | Electric |
| Operator type | - | Pedestrian |
| Rated capacity/rated load | Q(kg) | 1500 |
| Load centre distance | c(mm) | 600 |
| Load distance, centre of drive axle to fork | x(mm) | 951/1021 |
| Wheelbase | y(mm) | 1236/1306 |
| Service weight | kg | 114 |
| Axle loading, laden front/rear | kg | 410/1204 |
| Axle loading, unladen front/rear | kg | 85/29 |
| Tyres | - | Polyurethane (PU) |
| Tyre size, front | - | Φ210×75 |
| Tyre size, rear | - | Φ80×93/Φ80×70 |
| Wheels, number front/rear (x = driven wheels) | - | 1×2(4) |
| Tread, rear | b11(mm) | 390/525 |
| Max. lift height | h3(mm) | 110 |
| Height drawbar in driving position min./max. | h14(mm) | 635/1200 |
| Height, lowered | h13(mm) | 80 |
| Length to face of forks | l2(mm) | 430 |
| Overall width | b1/b2(mm) | 550/685 |
| Fork dimensions DIN ISO 2331 | s/e/l(mm) | 53/160/1150(1220) |
| Fork spread | b5(mm) | 550/685 |
| Ground clearance, centre of wheelbase | m2(mm) | 27 |
| Aisle width for pallets 1000 × 1200 crossways | Ast(mm) | 2180/2250 |
| Aisle width for pallets 800 × 1200 lengthways | Ast(mm) | 2050/2085 |
| Turning radius | Wa(mm) | 1380/1450 |
| Travel speed, laden/unladen | km/h | 4.3/4.5 |
| Lift speed, laden/unladen | m/s | 0.016/0.02 |
| Max. gradeability, laden/unladen | % | 5/20 |
| Package Dimensions | Package Weight |
|---|
